WeBaX Standard filter bags
Efficient filtration for demanding industrial applications - reliable, powerful, versatile.
Our WeBaX standard filter bags from Schwegmann Filtrations-Technik offer you first-class filter solutions that are well established in German industry. Whether for the production of paints and varnishes, printing inks, cooling and process water, chemicals, adhesives or solvents - our filter bags are the answer to demanding filtration requirements. They are ideal for applications where open filtration is no longer sufficient, whether due to higher throughputs, pressures, temperatures or aggressive media.
With plastic collar
With rings
| Technical data | |
|---|---|
| Material | Screen fabric PA = polyamide monofilament PES = polyester monofilament PS = polypropylene monofilament PAC = polyamide carbon monofilament PTFE or ETFE = PTFE/ETFE monofilament Needle felts PE = polyester needle felt P = polypropylene needle felt NY = polyamide needle felt PTFE = PTFE needle felt NX = Nomex® needle felt |
| Dimensions | R1: 180 mm diameter x 430 mm length R2: 180 mm diameter x 810 mm length R5: 152 mm diameter x 528 mm length (X100) R10: 105 mm diameter x 230 mm length R20: 105 mm diameter x 380 mm length RS: according to your specifications |
| Open screen area | R1: 0,25 m² R2: 0,50 m² R5: 0,20 m² R10: 0,08 m² R20: 0,13 m² |
| Volume | R1: 9 Liter R2: 18 Liter R5: 7,5 Liter R10: 1,4 Liter R20: 2,5 Liter |
| Max. differential pressure | 2,5 bar |
| Recommended differential pressure | 0,8-1,5 bar |
| Maximum flow rate | R1: 20 m³/h R2: 40 m³/h R5: 18 m³/h R10: 6 m³/h R20: 12 m³/h |
| Maximum temperature | PA = 120°C PES = 120°C PS = 80°C PAC = 120°C PTFE/ETFE = 260°C PE = 120°C P = 80°C NY = 120°C PTFE = 260°C NX = 205°C |
| Rings and collars | M = Galvanized steel ring E = Stainless steel ring K = Plastic collar (standard PPP) K(PES) = Plastic collar (standard PES) KS = Plastic collar (PPS) KS(PES) = Plastic collar (PES) SAN = Plastic collar (Santoprene) KI = Plastic ring (sewn in) E(PTFE) = Stainless steel ring, PTFE coated |
| Material (monofilament textile) | |||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mesh opening (µm) | 1 | 5 | 10 | 15 | 20 | 25 | 30 | 40 | 45 | 50 | 55 | 56 | 60 | 70 | 80 | 100 | 125 | 150 | 180 | 200 | 250 | 300 | 350 | 375 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1300 | 1500 | 1800 | 2000 |
| Polyamide monofilament (PA 6 and PA 6.6) | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • |
| Polyester monofilament (PES) | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | • | |||||||
| Polypropylene monofilament (PS) | • | • | • | • | • | • | • | • | • | • | • | ||||||||||||||||||||||||
| Material (monofilament textile) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Mesh opening (µm) | 82 | 105 | 120 | 145 | 160 | 205 | 245 | 402 | 510 | 600 |
| Polyamide Carbon monofilament (PAC) | • | • | • | • | • | • | • | • | • | • |
| Material (monofilament textile) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mesh opening (µm) | 50 | 80 | 150 | 200 | 250 | 300 | 400 | 420 | 500 | 600 | 850 | 1000 | 1800 |
| PTFE monofilament (PTFE) | • | • | • | • | • | • | • | ||||||
| ETFE monofilament (ETFE) | • | • | • | • | • | • | • | • | • | ||||
| Material (needle felt) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Filter fineness (µm) | 0,5 | 1 | 5 | 10 | 25 | 50 | 75 | 100 | 150 | 200 |
| Polyester needle felt (PE) | • | • | • | • | • | • | • | • | • | • |
| Polypropylene needle felt (P) | • | • | • | • | • | • | • | • | • | • |
| Polyamide needle felt (NY) | • | • | • | • | • | • | ||||
| PTFE needle felt (PTFE) | • | • | • | • | ||||||
| Nomex® needle felt (NX) | • | • | • | • | • | • | • | |||
| Codierung | ||||
|---|---|---|---|---|
| Material | Mesh opening I filter fineness | Size of filter bag | Ring I Collar | Seam inside |
| PA | 100 | R1 | K | IN |
| PA=Polyamide monofilament PES=Polyester monofilament PS=Polypropylene monofilament PAC=Polyamide Carbon monofilament PTFEMO=PTFE monofilament ETFE=ETFE monofilament PE=Polyester needle felt P=Polypropylene needle felt NY=Polyamide needle felt PTFE=PTFE needle felt NX=Nomex® needle felt | according to table mesh opening and filter fineness | R1=Size 1 R2=Size 2 R10=Size 3 R20=Size 4 R5=Size X100 RS=Special size | M=galvanised steel ring E=stainless steel ring K=plastic collar (standard PPP) K(PES)=plastic collar (standard PES) KS=plastic collar (PPS) KS(PES)=plastic collar (PES) SAN=plastic collar (Santoprene®) KI=plastic ring (stitched inside) E(PTFE)=stainless steel ring, PTFE coated | IN=yes plain=no |
